Calibration Basic
Calibration for precise transformation from pixel to real world coordinates
The Calibration and Rectification license provides you with a pylon vTool to quickly and easily calibrate cameras for distortion correction and real world coordinate transformation. Create a precise transformation model that converts pixel coordinates of object positions, angles, or dimensions to real-world values.
pylon vTools are part of Basler’s pylon Software Suite.
General Information
| Order Number | 20080 |
|---|---|
| Manufacturer | Basler |
| Type | pylon vTool |
Software
| License (Variant) | Basic |
|---|---|
| License Information | Unlimited use per system |
| License Description | Single image, single camera calibration for entocentric cameras |
| Operating System |
|
| vTool Features | Calibration |
Manufacturer
| Basler |
|---|
| Basic | Pro |
|---|---|---|
Calibration | ||
Rectification/Distortion correction | • | • |
Printable calibration plate sizes: 60 mm, 120 mm, 240 mm, 400 mm | • | • |
Calibration of real-world coordinate system manually and via positions of Aztec codes | • | • |
Division distortion model | • | • |
Polynomial distortion model | • | |
Perspective projection model | • | • |
Parallel projection model | • |
