Geometric Pattern Matching Basic
Edge-Based Algorithm for Simple and Robust Recognition of Shapes, Logos and Objects
Geometric Pattern Matching licenses provide pylon vTools for easy training of shape models and high-performance, adjustable recognition of trained shapes on live images. Create shape models by marking areas on live images or on images from files. An edge detection algorithm automatically detects the adjustable contours for shape recognition and enables a fast and easy training process. Images can be aligned with object positions from matching for further processing steps.
pylon vTools are part of Basler’s pylon Software Suite.
General Information
| Order Number | 20116 |
|---|---|
| Manufacturer | Basler |
| Type | pylon vTool |
Software
| License (Variant) | Basic |
|---|---|
| License Information | Unlimited use per system |
| License Description | Single pattern search, 360° rotation, without further scaling. |
| Operating System |
|
| vTool Features |
|
Manufacturer
| Basler |
|---|
Basic | Pro | |
|---|---|---|
Geometric Pattern Matching | ||
Search pattern from stored image | • | • |
Search pattern from live image | • | • |
Adjustable Timeout | • | • |
Adjustable contrast for teaching | • | • |
Adjustable matching score level | • | • |
Position accuracy | pixel precision | sub-pixel precision |
Adjustable number of matches per image | • | • |
Adjustable reference point | • | • |
Polarity settings | • | |
Adjustable search angle | always 360° | • |
Anistropic scaling levels | • | |
Adjustable scaling level | • | |
Image Alignment | • | • |
